GXY-1 Exploration Drilling Machine
GXY-1 Exploration Drilling Machine
GXY-1 Exploration Drilling Machine
GXY-1 Exploration Drilling Machine
GXY-1 Exploration Drilling Machine

GXY-1 Exploration Drilling Machine

Model NO.
GXY-1
Delivery
FOB
Minimum order quantity
1 set
Supply Ability
200 set / Year
Country of Origin
CN
Stock Time
14 Days
Quantity:

Parameters

Drilling diameter (mm)

150, 76, 46

Drilling depth (m)

40, 160, 200

Output speed of power head (r/min)

Positive: 61-654 (4th gear)

Counter: 45

Stroke (mm)

500

Maximum added pressure (KN)

15

Maximum lifting force (KN)

25

Rig holding shackle

Ball card type

Way to make way for orifice

Power head hydraulically controlled backward moving

Hoist lifting capacity (KN)

15

Lifting speed (m/s)

0.22, 0.95, 1.95, 5.3

Diesel engine model and power (kw)

S1100M, 11

Motor model and power (kw)

Y160M-4, 11

Dimension (L x W x H) (mm)

1800×1200×1500

Weight (kg)

500

Characteristics

1. The drilling rig is suitable for engineering geological investigation, general exploration of solid deposits, blasting holes and inspection holes for a variety of concrete structures.

2. According to the different strata, we can choose carbide bit and spiral diamond bit to drill.

3. The rig has large output power, large output torque and strong drilling capability.

4. It is equipped with a hydraulic driving mechanism.

5. The drilling rig adopts ball chuck structure.

6. The machine makes way for the orifice through the liquid-controlled displacement device, thus promoting efficiency.

7. In hard and massive strata, we use the high-speed model for diamond drilling.

8. It can be equipped with a towing structure or a pedrail chassis to enhance maneuverability.

9. The rig is compact in structure, small in size, light in weight, convenient in teardown and installation.

10. It fit in hilly mountainous areas.

Advantages

1. Easy to installation.

2. Strict quality management system.

3. Superior equipment.

4. Professional services.

5. High quality products.

6. Variety types for selection.

7. Competitive price.

8. Prompt delivery.
