BW-250 mud pump
BW-250 mud pump
BW-250 mud pump
BW-250 mud pump
BW-250 mud pump

BW-250 mud pump

Model NO.
BW-250
Delivery
FOB
Minimum order quantity
1 set
Supply Ability
200 set / Year
Country of Origin
CN
Stock Time
14 Days
Quantity:

Parameters

Style

Horizontal

Type

Single-acting

Number of cylinder

3

Cylinder liner dia.(mm)

80;65

Stroke (mm)

100

Stroke per Minute

200;116;72;42

Displacement (L/min)

200,145,90,52;166,96,60,35

Pressure (MPa)

25,45,60,60;40,60,70,70

Transmission Shaft Rotating Speed or Drive Shaft Input Speed (r/min)

500

Power (by client′s request)

15KW

Volumetric efficiency (%)

83

Overall efficiency(%)

70

Suction pipe dia,(mm)

76

Scupper pipe dia.(mm)

51

Dimensions (L×W×H)

1000×995×650

Weight(kg)

500

Characteristic

1. Bw-250 mud pump is a horizontal three cylinder reciprocating single acting piston pump.The mud pump is one of the main supporting equipment for geological exploration.

2. Its main function is to supply flushing fluid (mud or water) to the drilling hole during the core drilling process, so as to make it circulate in the drilling hole, so as to carry cuttings back to the ground, cool and lubricate the drill bit and drill tool, protect the hole wall from collapse, and also serve as cement slurry perfusion pump in foundation treatment engineering

3. The water-cement ratio of cement slurry can reach 1:1, with small size, compact structure, easy to install and disassemble, easy to carry and other characteristics

4. The pump can be used as a supporting equipment for the 1000 meters large aperture rig, which has four emissions, and the washing liquid should not contain the chemical impurities that corrode the metal and rubber.

Advantages

1. We can customize special hardware as customer demand.

2. Technical service for assembling.

3. Variety types for selection, prompt deliver.

4. Well-equipped with extensive sales network.

5. Advanced Production equipment and production technique.

6. Competitive Price (Factory direct price) with our good service.

7. Different designs are available according to customer requests.

8. Excellent quality testing equipment, 100% inspection on critical.
