BW-160 mud pump
BW-160 mud pump
BW-160 mud pump
BW-160 mud pump
BW-160 mud pump

BW-160 mud pump

Model NO.
BW-160
Delivery
FOB
Minimum order quantity
1 set
Supply Ability
200 set / Year
Country of Origin
CN
Stock Time
14 Days
Quantity:

Parameters

Model

BW-160

Cylinders

Single cylinder

Stroke(mm)

85

Diameter of liner(mm)

φ95

Stroke per minute(b/min)

165

Displacement(L/min)

160

Pressure(Mpa)

1.3

speed(r/min)

951

Power(kw)

15kw diesel engine

Weight(kg)

90 (exclude engine)

Dimensions(L×W×H)

1100×725×965

Characteristic

The bw-160 mud pump is a pump that provides flushing fluid for blasting holes in geological exploration. It can also be used to supply drilling fluid for geological bedrock drilling rig. The main function of the mud pump is to provide drilling fluid to circulate through the drilling process and bring cuttings back to the surface to keep the bottom hole clean and lubricate the bit and drill tools.

Advantages

1. Easy to installation.

2. Strict quality management system.

3. Superior equipment.

4. Professional services.

5. High quality products.

6. Variety types for selection.

7. Competitive price.

8. Prompt delivery.
